Solo |
SoloDL |
| Speed |
By GPS |
By GPS or through ECU Connection |
| Time measurement |
Over GPS
- measuring accuracy 1/100 sec.
- Up to 5 split times
- Separate settable Start and Finish line
- Predictive Lap time |
| Acceleration |
Internal Triaxial Acceleration sensor |
| Sum scan rate |
GPS data and triaxial accelerometer at 10 Hz |
Max 5000 Hz depending upon ECU data
stream specification |
| Connector |
1x socket (binder) 712, 3-pins
1x Mini-USB |
1x socket (binder) 712, 5-pins
1x socket (binder) 712, 7-pins
1x Mini-USB |
| Data storage |
Non-volatile internal 16 MB memory |
| Power supply |
Internal rechargeable Lithium-battery
External 8-16 V over power supply network |
Internal rechargeable Lithium-battery
External 8-16 V over power supply network
When connected to OBDII, SoloDL gets power from OBDII |
| Updates |
Software and Firmware Updates
free over the Internet |
| Dimensions |
98 x 78 x 30 mm |
| Weight |
240 g |
| Protection class |
IP67 |
